oki microline 5720/5790 printer Dot matrix Printer

oki microline 5720/5790 printer Dot matrix Printer

Product details of oki microline 5720/5790 printer Dot matrix Printer

Printing MethodSerial Impact Dot Matrix MethodPrint HeadDual 9 PinDot Wire Diameter0.3 mmPrint DirectionBidirectional/Unidirectional printing, Short line-seeking printingGraphic ResolutionMax. 240(H) x 216(V) dpiPrint SpeedSuper Speed Draft : 700 cps, High Speed Draft : 600 cps, Draft : 450 cps, Near Letter Quality : 113 cpsLine Feed Pitch4.23mm (1/6 "), 3.18mm (1/8 "), n x 0.35mm(n/72 ") (n=1-85), n x 0.18mm(n/144 ") (n=0-255), n x 0.12mm(n/216 ") (n=0-255)Feed Speed5.25 inches per secondFeed Rate4.23mm(1/6”) line feed: Approx. 47 millisecondsPaper RouteTractor feeder (Front), Tractor feeder (Rear), Tractor feeder (Bottom), Manual (Top), Manual (Front), Roll paper stand, Cut sheet feeder (Rear)Character PitchSuper Speed Draft : 12.0 cpi

High Speed Draft : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi

Draft : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi

Near Letter Quality : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi, PropotionalPrinting Width80 characters/line at ANK 10 cpiInterfaceIEEE1284-1994 Bi-directional Parallel, USB 2.0 (Full Speed), (Optional) 100BASE-TX/10BASE-T, (Optional) RS-232C (25pin)EmulationOKI Microline, ESC/P emulation, IBM ProPrinter emulationSupported OS (Click here for latest OS)Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64Receive BufferMax. 128KBResident FontHigh Speed Draft, Draft, NLQ Courier, NLQ Gothic, OCR-B, Scalable Courier, Scalable GothicFont StyleBold, Double Width, Double Height, Emphasized, Italics, Over score, Underline1-D BarcodeUPC-A, UPC-E, EAN8, EAN13, Code39, Interleaved 2 of 5 (ITF), Code128, POSTNET, Codabar (NW-7), IndusPaper TypeContinuous paper, Continuous copying paper, Cut sheet, Card, Envelope, LabelPaper Weight AdjustmentManualPaper SizeContinuous paper: Width 76.2-254.0mm x Length 76.2-558.8mm

Single part paper: Width 99.1-256.5mm x Length 99.1-363.0mm

Multi part paper: Width 76.2-254.0mm x Length 76.2-558.8mmPaper WeightContinuous paper : 45 - 90 gsm

Single part paper : 45 - 90 gsm

Multi part paper : 35 - 40 gsmCopy CapabilityNormal print mode: original + 5sheets(Total Thickness < 0.36mm)

High copy print mode: original + 6 sheets(Total Thickness <0.36mmDimensions(WxDxH)414 x 320 x 159 mmOperating EnvironmentOperating: 5 - 35 °C, 20 - 80 %RH

Storage: -10 - 50 °C, 5 - 95 %RH

No condensationPower SourceSingle phase 220 - 240 VAC ±10%, 50/60 Hz ±2%Power ConsumptionOperating: Max. -W (ISO10561 (Draft, Range1) Printing Approx. 59W)

Idle: Approx. 15W

Sleep: < 1.5WNoise LevelOperating :Approx. 57 dBA

Quiet Mode: < 52 dBAMTBF(Mean Time Before Failure)25,000 hoursRibbon LifeBlack : 8 million charactersPrint Head LifeApprox. 600 million strokes/ pinIn the BoxRibbon cartridge, Power cable, CD-ROM, Others

Specifications of oki microline 5720/5790 printer Dot matrix Printer

SKU DQECMP09

Printer Connectivity TypeUSB

Input Tray Capacity (papers)151-200 Shet

Double Sided PrintingYes
